TRILAB DeltiQ 2
Different at First Sight
.. and not just in its looks. The TRILAB DeltiQ 2 is a reliable printer made with high-quality parts that’s used for professional printing in business and in the lab.
6 reasons to get the TRILAB DeltiQ 2
1 Top-notch prints
The model is static during printing, which results in perfect quality print over the entirety of the model’s height.
2 Unconventional
Unconventional and unexpected model orientation can be safely printed for an even better surface quality.
3 Complete solution
A tuned printer for professionals, a complete made-to-order package — starting from a demo print, a suitable configuration proposal, delivery with installation to service and application support.
4 Universal
You will be blown away by the range of materials that can be processed by this printer - from common filaments, to modern and advanced materials such as composites or flexibles.
5 Smart
Control the printer according to your needs - with your hand, using the DeltaControl wireless display, using our app in your smartphone or remotely using the WebControl interface.
6 Beautiful
As a unique industry standout, you’ll have trouble keeping your eyes of it thanks to the grace of the delta movements.
Made from the best parts
Revolutionary Printer Control
Control the printer according to your needs. In the palm of your hand using the DeltaControl wireless display, which can be safely stowed in the charging dock, using the WebControl interface on your PC/Mac or using the DeltaControl app in your smartphone. And all of this both locally or remotely.
TRILAB DeltaControl
- Take the display anywhere
- Everything you need to control the printer
- High DPI and great readability of the display
- Display Hub with integrated charger
- Android smartphone included
- Intuitive interface
Web Control
- Control the printer from PC, Mac or your Tablet
- Worldwide remote access (can be disabled)
A support you can depend on
We do not produce thousands of printers. As a result, we guarantee exquisite product support to every customer worldwide. Something other vendors can only promise and HARDLY deliver.
Print anything
With DeltiQ 2 you are unstoppable in your pursuit for perfect prints. Wide palette of supported materials, two perfect extruders and stimulating freedom of the print orientation. That's what conjures a smile on your face.
Standard models and materials
Standard models from PLA, PETG or CPE materials printed on DeltiQ 2 with ease, fast and in perfect surface quality.
Bigger and difficult models
Bigger and more difficult models from PLA, PETG or CPE, printed on DeltiQ 2 without or with limited need of supports from the same material.
Technical and composite materials
Models from technical materials like ABS/ASA, Nylon or Nylon with CF printed on DeltiQ 2 simply by using hardened nozzle.
Flexible materials
Printing from TPU or TPE is piece of cake using unique delta printer - TRILAB DeltiQ with FlexPrint extension.
Wax filaments
Positive models for the subsequent production of precision casting molds, simply printed on DeltiQ 2 using wax or PMMA filaments.
Multifilament models
Combine multiple colors or totally different materials and print them at the same time using TRILAB DeltiQ with QuadPrint extension.
They trust our printers
TRILAB FlexPrint
With a unique remote direct drive extruder your TRILAB DeltiQ will be able to print even the softest flexible materials with no hassle.
Nimble direct drive is the optional addon. But hand on hearth – you will love this solution from the start!
One material is not enough?
Meet TRILAB QuadPrint
We make no compromises even when it comes to multi-material printing.
TRILAB DeltiQ 2 keeps one nozzle and one extruder because it's 100% reliable and trouble-free configuration. Instead of changing the extruder, we're adding a smart external device called Mosaic Palette 2. Just like that, you will be able to print from up to 4 print materials at a time.
And with no hassle, because we will ensure that DeltiQ 2 and Palette 2 work simply and in perfect symbiosis.
There's a lot you can do with TRILAB QuadPrint:
- print from 4 different colors of PLA or PETG
- print from soluble supports (e.g. PLA with BVOH)
- combine multiple materials (e.g. PLA with flexible TPU)
- combine more colors, materials and soluble supports at once
A right fit for every project
TRILAB DeltiQ 2
Standard model with a decent print volume.
TRILAB DeltiQ 2 Plus
Extended model with much bigger print volume.
TRILAB Rental
Need a printer for a project? Or a whole farm? Contact us!
Printer Specifications
Printer Specification |
|
|---|---|
| Print technology | Fused Deposition Modelling (FDM) |
| Print Volume | DeltiQ 2: Ø 250mm (X, Y) × 300mm (Z) DeltiQ 2 Plus: Ø 250mm (X, Y) × 500mm (Z) |
| Printhead | Light printhead; E3D V6 all-metal hotend; Easily swappable as a complete assembly |
| Extruder | E3D Titan geared extruder, bowden setup Optional “FlexPrint Edition” - Zesty Nimble extruder for demanding and flex filaments |
| Print Platform | Massive, 5 mm thick aluminium heated print base Swappable magnetic PrintPad sheet with PEI surface PrintPad sheets with alternative surfaces available |
| Control interface | Wireless 5.45“ IPS “DeltaControl“ display, incl. charging dock DeltaControl app; iOS/Android WebControl interface; PC/Mac |
| Connectivity | LAN or WIFI with local or remote access 3x USB: WIFI/LAN module/USB drive/Webcam/Palette 2 |
| Print Monitoring | Multicolor LED indicator for visual print status overview Built-in camera with print illumination |
| Supported input formats | STL, gcode; standard slicers (Kisslicer, Cura, PrusaSlicer, Slic3r, Simplify3D) |
| Dimensions and weight (printer) |
DeltiQ 2: 41×50×81 cm / 10 kg DeltiQ 2 Plus: 41×50×98 cm / 18 kg |
| Dimensions and weight (whole package) |
DeltiQ 2: 49×53×105 cm / 18 kg DeltiQ 2 Plus: 49×53×105 cm / 20 kg |
| Power | Input 100-240 V, Output 24 V, 250 W |
Print Output |
|
|---|---|
| X/Y resolution | According to the used nozzle in the range of 0.25-1.2 mm, standard 0.4 mm |
| Z resolution | A layer height of down to 50 microns, maximum layer height depends on the used nozzle |
| Maximum nozzle temperature | Standard up to 300 °C, with upgraded temperature sensor up to 350 °C |
| Maximum print bed temperature | 105 °C |
Materials |
|
|---|---|
| Filament diameter | 1.75 mm |
| Compatible materials | Standard: PLA, PETG/CPE, ABS/ASA, PETG-CF, PC, PP, PVA, BVOH, PACF, PAGF FlexPrint extension: nylon/PA, flexible materials (TPA, TPU) |
| Multifilament printing | TRILAB “QuadPrint Edition“: multifilament solution for up to 4 filament colors or various materials or combination with soluble/breakaway support materials |
